AIR15 | 两分频有源扩声音箱

产品简介

通过为每个驱动器使用不同的放大器类型,AIR15 扩声音箱利用 D 类和 A/B类 放大器的各自优势,在音箱的整个频率范围内提供最佳响应。

AIR15: Versatile, customizable, and easy to transport.

Compact and lightweight, AIR15 active loudspeakers provide a rich, extended low-end and natural high-frequency extension in an enclosure that will easily fit in the backseat of a small car. Backed by 1,200W (dynamic) of Class D/Class AB power and enhanced with easy-to-use digital tuning functions, the AIR15 gives you all the power and tools you need for both mobile and installed sound.


The best of two worlds.

Each type of power amplifier has advantages and disadvantages. By employing different amplifier types for each driver, AIR15 loudspeakers use the respective strengths of Class D and Class A/B amplifiers to provide optimal response throughout the speaker's frequency range. A 500W (continuous), Class D amplifier powers the 15-inch low-frequency driver, providing efficient, clean power for gut-shaking low end when you need it. A 200W (continuous), Class A/B amplifier powers the 1.35-inch high-frequency driver, delivering a natural sounding, "AIR-y" high end. The combination can deliver up to 124 dB SPL of sweet, clear sound between 47 Hz and 20 kHz.


Fast and easy customization.

The AIR15 loudspeaker is equipped with an easy-to-use signal processor that makes it simple to customize your loudspeakers with the push of a button. Presets customize the AIR15’s response for use as front-of-house mains; as monitor wedges; for music playback (e.g., for DJs); for enhanced low end and a warmer sound; and for improved speech intelligibility. Treble and bass controls let you boost or cut by 10 dB to compensate for room anomalies. Location presets let you optimize performance for stand and bracket mounting as well as flown installations.


Versatile mounting for a variety of applications.

The AIR15’s molded plastic cabinet can be mounted in several ways, providing tremendous versatility. The multi-angle enclosure sports nonskid rubber feet on the bottom for upright front-of-house use and nonskid rubber feet on one side for stage monitor applications. Rig the speaker using M10 fly points or ground-stack it for portable applications. Mount it on a tripod or atop an AIR-series subwoofer using an optional sub pole. The integrated dual-position pole mount lets you aim the speaker level or at a 7.5˚ downward tilt. And the AIR15 is easy to transport, thanks to its top-mounted handle.


You’ll be floored.

If you place a loudspeaker against a hard surface such as a wall or floor, the low frequencies emitted from the rear of the enclosure propagate back into the room. This effect, called “half-space loading,” can increase the output of bass frequencies by as much as 6 dB, and it is an unavoidable issue with floor monitors. Most PA speakers in this class simply roll off excess low frequencies with a highpass filter—a half-baked compensation for half-space loading. In contrast, AIR-series full-range loudspeakers offer a Monitor preset that uses DSP to retune the speaker to both compensate for bass buildup and maintain a tight mid-bass response, while suppressing problematic frequencies to reduce feedback.


Flexible inputs.

AIR-series full-range loudspeakers offer a choice of inputs so you can use them with a variety of sources. You get two combo XLR mic/TRS line inputs, each with a Class A microphone preamplifier and independent gain control. A stereo 1/8” connection admits signals from smartphones, tablets, and other consumer audio devices. These signals can be combined with the AIR15’s internal mixer, and a balanced XLR Mix output lets you send pass the signals to other AIR-series loudspeakers.


A sweet-sounding solution.

With their “best of both worlds” power-amp configuration, carefully programmed DSP presets, versatile mounting options, flexible inputs with onboard mixing, and other professional features, PreSonus AIR-series loudspeakers are an excellent choice for both mobile and installed sound. You’ll love their easy transportability and their affordability. But the best thing about AIR-series loudspeakers is their clear, natural, “AIR-y” sound. Don’t just take our word for it, though. Check out AIR-series loudspeakers at your favorite PreSonus dealer.


Six-year warranty lets you rest easy.

When you choose ULT or AIR loudspeakers, you choose confidence. Rest assured that your new PreSonus speakers are in it for the long haul. We take our build quality seriously, and if anything goes wrong with them in your first six years of ownership (assuming you don't throw them in a swamp or anything like that) the repair or replacement is on us.


技术指标

主要部件

  • 混合“最佳组合”,1200W(动态)功率放大器配置

  • 低频驱动:500W(持续功率),D级放大器

  • 高频驱动:200W(持续功率),A/B级放大器

  • 峰值时声压级:132dB

  • 1.35英寸高频压缩驱动器

  • 带有2.5英寸音圈的15英寸低音扬声器

  • 40 Hz - 20 kHz 的频率响应范围

  • 最大132 dB 声压级

  • 90度 x 60度 (横向x 垂直)分散模式

  • 自带两路 combo XLR 和 1/4 输入及一路总平衡输出

控制

  • 操作简洁的DSP性能预设

  • DJ音乐回放

  • 常规前场增强,为实现“暖声”的低频增强

  • 为地板放置的性能优化

  • 为演讲设计的人声语言辨析度优化

  • 使用支架或三脚架时的性能优化预设

  • 高频响应±10 dB

  • 低频响应±10 dB

  • 为墙体悬挂使用设计的性能优化预设

  • 为悬浮放置设计的性能优化预设

声学性能

  • 构造:有源两分频

  • 频响范围(-3dB):47 Hz 至20 kHz

  • 频响范围(-10dB):40 Hz 至20 kHz

  • 最大输出功率:124 dB SPL

  • 指向性(角度):90?x 60?

换能器

  • 低频驱动器:15英寸(2.5英寸音圈)

  • 低频驱动器:1.35英寸

功率放大器

  • 功放类型: Class D(低频),Class AB(高频)

  • 整体系统功率:1,200W动态

  • 低频功率:900W

  • 高频功率:300W

连接及控制

  • 输入:2 x XLR/TRS麦克/线路combo,1×1/8英寸TRS立体声

  • 输出:1 x XLR混合输出

DSP

  • DSP 特点:LCD屏,带有EQ及多重预设

外壳

  • 箱体:H-PP铸造

  • 格栅:1.2毫米钢制

  • 把手:侧面一个,顶部一个

  • 悬挂点:顶部两个,背部一个

  • 杆装固定:支持双位置(0°,7.5°)

  • 体积(高 x 宽 x 深):19.7英寸x 18.5英寸 x 30.7英寸 (500毫米x 470毫米x 781毫米)

  • 重量:43.6磅(21千克)

电源

  • 电源输入:115V/230V ~ 50/60可选

  • 最大电流:3.5A (230V-50 Hz), 7A (120V)
